Lifepo4 BMS PCM Battery Protection Board 16S 25A 45A FR4 Material
  • Lifepo4 BMS PCM Battery Protection Board 16S 25A 45A FR4 Material
  • Lifepo4 BMS PCM Battery Protection Board 16S 25A 45A FR4 Material
Lifepo4 BMS PCM Battery Protection Board 16S 25A 45A FR4 Material

Lifepo4 BMS PCM Battery Protection Board 16S 25A 45A FR4 Material

Place of Origin China
Certification ISO9001/Iso14001/CE/ROHS
Model Number 16S 25A 45A Hardware BMS Battery Management System
Product Details
Copper Thickness::
1OZ
Min. Hole Size::
0.25mm
Base Material::
FR4
Surface Finishing::
Spray Paint
BMS Type::
3.2V Rated
Common Port::
With Balance
Highlight:

16S BMS PCM Battery Protection Board

,

25A BMS PCM Battery Protection Board

,

45A 16S Lifepo4 BMS

Payment & Shipping Terms
Minimum Order Quantity
5pcs
Price
To be negotiated
Packaging Details
Packed in export carton Box
Delivery Time
To be negotiated
Payment Terms
T/T, Western Union, MoneyGram
Supply Ability
100000pcs/month
Product Description

16S 25A 45A Hardware BMS Battery Management System Lifepo4 Battery Bms UPS 48v 60 battery management system



3.2V BMS Main Parameters
Charging Volt
3.65*Series
Discharge current same as bms
Charge Current
Depends on parameters
Overcharge protection
3.65V+0.025V
Detection Delay: 1000+500ms
Release Volt
3.55V+0.05V
Overdischarge Protection
2.35+0.1V
Detection Delay: 1000+500ms
Release Volt
2.7+0.1V
Balance Function
3.5V+0.025V
Detection Delay: 100+50ms
Balance Current
36+5MA
Over current Protection
50+15MV
Detection Delay: 1000+500ms
Current Protection
300+50A,450+50A,600+60A
Short Circuit Protection
YES
Detection Delay: 300US
off load

Temperature protection
Charging Temp: 55 degree
Discharging Temp:75 degree
Recover while temperature reach normal charging temp

Self Consumption
Working :35uA
Rest :<10uA
Working Temp
-30 to 80 degree
3.7V BMS Main Parameters
Charging Volt
Series*4.25V
Discharge Current :Same as bms current
Charge current
:Depends on specification
Overcharge protection
4.25+0.025V
Detection Delay: 1000+500ms
Release Volt
4.15+0.05V
Overdischarge protection
2.75+0.1V
Detection Delay: 1000+500ms
Release Volt
3+0.1V
Balance Function
4.15+0.025V
Detection Delay: 100+50ms
Balance Current
42+5MA
Overcurrent Protection
50+15mv
Detection Delay: 1000+500ms
Current protection
300+50A 450+50A 600+60A
Short circuit protection
YES
Detection delay
300us
Off load
Temperature
Protection
Charging temp: 55 degree
Discharging temp 75degree
Release method
Temperature recover to normal charging temp
Self consumption
Working <35ua
Rest <10ua
Working Temp
-30 to 80 degree



Lifepo4 BMS PCM Battery Protection Board 16S 25A 45A FR4 Material 0
